AM5218MZTW

Marca:
Codice del prodotto: AM5218MZTW

Cambia tra osservazioni micro e macro con il microscopio a campo visivo ampio Dino-Lite AM5218MZTW. L'AM5218MZTW è un microscopio in streaming 720p con connettività HDMI diretta a display LCD e TV, adatto per applicazioni che richiedono solo un monitor.


hdmiresMag 10 220EDOFEDRAMRPolariserPolarisermag


Le principali caratteristiche dell'AM5218MZTW sono:

• Interfaccia HDMI
• Alta risoluzione ottica
• Ampio campo visivo (WFOV)
• Pulsante Microtouch
• Cappucci intercambiabili
• HD 720p
• E altro ancora...

MAGNIFICATION RATE WORKING DISTANCE FIELD OF VIEW(X) FIELD OF VIEW(Y) DEPTH OF FIELD
T Zone
50 10 9 7 3
40 30 11 9 4
30 60 15 12 6
20 120 23 19
15 170 30 24
Listed values may differ slightly       Unit = mm



MAGNIFICATION RATE WORKING DISTANCE FIELD OF VIEW(X) FIELD OF VIEW(Y) DEPTH OF FIELD
W Zone
30 10 14 11 6
20 30 25 20
15 40 31 25
10 60 41 33
5 170 98 78
Listed values may differ slightly       Unit = mm



Lighting
Light/ LED type White
Number of LEDs 8
LED on/off switchable: Yes
Infrared filter IR cut-filter >650 nm
Emission filter No
Polarizer Yes, linear
Optics
Magnification 10x ~ 50x
Macro zoom No
Working distance Standard
Lens type Glass with anti-reflection coating
Sensor
Sensor type CMOS
Resolution HD 720p
Maximum frame rate 60 fps
Compatibility
Interface HDMI
Wifi No
Housing
Housing material Metal housing
Magnification lock Yes
Dimensions 10.5cm (L) x 3.2cm (D)
Weight 125g
Features
Special feature No
Measurement No
Calibration No
Microtouch sensor Yes
ESD safe Yes
Information
Package contents Microscope, carry pouch, DVI & HDMI cable, power adapter, user manual, N3C-O- Open cap, N3C-C- Closed cap, N3C-D- Diffuser cap, N3C-E- Extension cap, N3C-L- Long cap, N3C-S- Side light cap
Warranty information 2 years European warranty
Regulatory approval CE, FCC, ROHS
Price range €900,00 - €1100,00
