AM5216ZTL

Brand:
Product Code: AM5216ZTL

The Dino-Lite AM5216ZTL connects directly to a VGA screen via a VGA (D-SUB) connector. It offers a high frame rate of up to 60fps at 1280x720 resolution, resulting in crystal clear images.


USBMag 10 2205 megapixel EDOFEDRAMR Polariser


Together with the long working distance of up to 15 centimeters the AM5216ZTL is the ideal choice in situations, where real time images are vital, such as working on PCB's or other miniature objects. By tapping the Microtouch sensor on the microscope, the image can be frozen for inspection of important details and by pressing the Microtouch sensor for 2 seconds the LEDs can be switched on and off. The built-in adjustable polarizer reduces glare and reflection on shiny objects, such as metal surfaces, electronics, plastics etc. (The AM5216ZTL replaces model AM5116ZTL.)

» Also available: AM5216TL without polarizer



MAGNIFICATION RATEWORKING DISTANCEFIELD OF VIEW(X)FIELD OF VIEW(Y)DEPTH OF FIELD
Listed values may differ slightly       Unit = mm
10 234.5 39.0 22 12
20 112.5 19.5 11 4.5
30 72.5 13.0 7.3 3.1
40 54.5 9.8 5.5 1.8
50 43.5 7.8 4.4 1.2
60 37.5 6.5 3.7 0.9
70 33.7 5.6 3.2 0.6
80 31.3 4.9 2.8 0.5
90 29.9 4.3 2.4 0.37
100 29.2 3.9 2.2 0.28
110 29.1 3.5 2 0.22
120 29.3 3.3 1.9 0.17
130 29.8 3.0 1.7 0.12
140 30.5 2.8 1.6 0.09



Lighting
Light/ LED type White
Number of LEDs 8
LED on/off switchable: Yes
Infrared filter IR cut-filter >650 nm
Diffuser available Yes (N3C-D included)
Emission filter No
Polarizer Yes, linear
Optics
Magnification 10x ~ 140x
Macro zoom No
Working distance Long
Lens type Glass with anti-reflection coating
Sensor
Sensor type CMOS
Resolution 1280x720 (720p)
Maximum frame rate 60 fps
Compatibility
Interface VGA (D-Sub)
Wifi No
Housing
Housing material Composite/ plastic housing
Magnification lock Yes
Dimensions 10.5cm (L) x 3.2cm (D)
Weight 105g
Cable length 0.6m
Features
Special feature No
Measurement No
Calibration No
Microtouch sensor Yes
ESD safe No
Information
Package contents Microscope, carry pouch, power adapter, front cover box, user manual
Warranty information 2 years European warranty
Regulatory approval CE, FCC, ROHS
Price range €600,00 - €800,00
