AM4013MTL

Marke: Dino-Lite
Artikelnummer: AM4013MTL

Dino-Lite Pro mit Aluminiumgehäuse sowie langem Arbeitsabstand und Microtouch. Das Aluminiumgehäuse bietet verbesserten Schutz und Haltbarkeit bietet, sieht gut aus und fühlt sich gut an.


USBMag 10 2205 megapixel EDOFEDRAMR Polariser


MAGNIFICATION RATE WORKING DISTANCE FIELD OF VIEW(X) FIELD OF VIEW(Y) DEPTH OF FIELD
20 151.0 19.6 15.6 6
30 101.0 13.0 10.4 3.4
40 77.2 9.8 7.8 2.2
50 64.1 7.8 6.3 1.65
60 56.2 6.5 5.2 .
70 51.3 5.6 4.5 .
80 48.3 4.9 3.9 .
90 46.6 4.3 3.5 0.8
Listed values may differ slightly       Unit = mm
Lighting
Light/ LED type White
Number of LEDs 8
LED on/off switchable: Yes
Infrared filter IR cut-filter >650 nm
Diffuser available No
Emission filter No
Polarizer No
Optics
Magnification 10-90x
Macro zoom No
Working distance Long
Lens type Glass with anti-reflection coating
Sensor
Sensor type CMOS
Resolution 1.3 Megapixel (1280x1024)
Maximum frame rate 30 fps
Compatibility
Interface USB 2.0
Operating system Windows 7,8,10 & 11, MacOS 10.9 and up
Included software DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Supported image formats (Windows) BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Supported video formats (Windows) WMV, FLV, SWF
Supported image formats (MacOS) JPEG, PNG
Supported video formats (MacOS) MOV
Imaging standards DirectShow, UVC
Wifi Wireless-ready, requires the WF-10 WiFi streamer (optional)
Housing
Housing material Metal housing
Dimensions 10.5cm (L) x 3.2cm (D)
Weight 140g
Cable length 1.8m
Features
Special feature No
Measurement Yes
Calibration Yes
Microtouch sensor Yes
ESD safe Yes
Information
Package contents Microscope, carry pouch, software CD, calibration target, user manual
Warranty information 2 years European warranty
Regulatory approval CE, FCC, ROHS
Price range €350,00 - €550,00
